Motive Gear

Differential Ring And Pinon Front And Rear Complete Kit

Differential Ring And Pinon Front And Rear Complete Kit

Regular price $878.99 USD
Regular price $878.99 USD Sale price $878.99 USD
Sale Sold out
Motive Gear offers some of the toughest drive train components on the market today. If you are looking for the largest line of performance ring and pinion gear options available with gear sets in a wide range of ratios for nearly every application, both on and off-road, check out Motive Gear. Motive Gear products can be found in the winner's circle at racing events worldwide. The superior quality of Motive Gear components is the result of years of racing development, outstanding design and state-of-the-art manufacturing methods. Extensive testing is performed on all products by our in-house engineers.
  • GTIN: 00698231100431
  • Brand Name: Motive Gear
  • Ring Gear Bolt Quantity: 10
  • Cover Bolt Quantity: 10
  • Gear Ratio: 4.09
  • Gear Ratio: 4.10
  • Pinion Shaft Diameter: 1.376 Front (D44-409F)
  • Pinion Shaft Diameter: 1.626 Rear (F8.8-410)
  • Ring Gear Tooth Quantity: 45 Front (D44-409F)
  • Ring Gear Tooth Quantity: 41 Rear (F8.8-410)
  • Pinion Spline Count: 26 Front (D44-409F)
  • Pinion Spline Count: 30 Rear (F8.8-410)
  • Ring Gear Rotation: Reverse Front (D44-409F)
  • Ring Gear Rotation: Standard Rear (F8.8-410)
  • Pinion Gear Tooth Quantity: 11 Front (D44-409F)10 Rear (F8.8-410)
  • Differential Case Design Type: Dana 44 Reverse
  • Differential Case Design Type: Ford 8.8
  • Ring Gear Outside Diameter: 8.5 Front (D44-409F)
  • Ring Gear Outside Diameter: 8.8 Rear (F8.8-410)
  • Ring Gear Material: 8620 Steel
  • Differential Carrier Break: 3.92 Ratio and Higher
  • Country of Origin: United States
  • Emissions : CARB Eligible
  • Life Cycle Status: Available To Order
  • Quantity of Each: 1
  • Package UOM: EA
  • Dimension: 16.0000 x 16.0000 x 12.0000 inches
  • Weight: 41.6990 lb
